✮F2.0 large aperture, more light inputs, clearer night vision |
✮Dual-core light panel, supports full-color night vision |
✮ISP image processing technology, preserving true colors |
✮Human detection, real time alerts |
Sorts |
Type |
Parameters |
System |
Operating system |
Linux |
Online visitor |
Supports 4 visitors at the same time |
APP |
O-KAM Pro |
Collection |
CPU |
Ingenic |
Memory |
512Mb |
Lens |
4mm |
Image sensor |
1/2.7" 1080p progressive scan CMOS sensor |
Minimum illumination |
0.5Lux (color mode), 0.1Lux (b&w mode) |
Sensor performance |
Support automatic white balance, automatic gain control and automatic backlight compensation |
Night vision |
Black and white night vision, full-color night vision |
Viewing angle |
Diagonal 91 ° |
Video |
Resolution |
1080P 1920x1080/15FPS/2 MP;1296P 2304x1296/15FPS/3 MP |
Night vision |
Black and white night vision, full-color night vision |
Compression standard |
H.264 main profile/Motion-JPEG/JPEG |
IR control |
IR-CUT, soft photosensitive control |
Bit rate |
128~4096kbps |
Image adjustment |
Brightness, contrast, OSD display |
Audio |
Input |
Built-in -38dB microphone |
Output |
Built-in 8Ω1W speaker |
Sampling frequency/bit width |
8KHz/16bit |
Compression standard/Bit Rate |
G711A |
Pan/Tilt |
Rotation angle |
Pan:310° tilt:115° |
Network |
Network interface |
10Mbps/100Mbps |
Network protocol |
TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P |
4G network(China) |
FDD:B1/B3/B5/B8 TDD:B34/B38/B39/B40/B41 WCDMA:B1/B5/B8 |
Storage |
External TF card |
Supports T-Flash cards (up to 256GB) |
Cloud storage |
Support cloud storage, users can purchase according to their needs. |
Alarm |
Alarm detection |
Motion detection, human detection, human framing, human tracking, and area detection |
Physical Indicators |
Rated voltage |
DC5V±12% |
Power consumption |
Power: 2.4W (0.48A) Maximum power: 3.85W (0.77A) |
Operating condition |
Working temperature: -10~45 ℃, working humidity<90% |
Weight |
N.W:190g, G.W:332g |
Camera size |
84x84x117mm |
Packaging box size |
90x90x185mm |
Carton size |
470x470x395mm, 50PCS/CARTON |
