✮Dual-Band WiFi High Speed & Stable |
✮4 MP Ultra HD |
✮Black light full color, presenting color image even with no supplement light |
✮F1.0 large aperture, 4 times more light intake, clearer night vision |
✮Soft light design, presenting a full color image in 24 hours |
✮ISP image processing technology, preserving true colors |
✮Human detection, real time alerts |
✮Remote access, view the monitoring areas anytime and anywhere |
Sorts |
Type |
Parameters |
System |
Operating system |
Linux |
Online visitor |
Supports 4 visitors at the same time |
APP |
O-KAM |
Collection |
CPU |
Sigmastar 337DE |
Memory |
1Gbit |
Lens |
4mm F1.0 |
Image sensor |
1/2.9 CMOS sensor |
Minimum illumination |
0.01Lux |
Sensor performance |
Support automatic white balance, automatic gain control and automatic backlight compensation |
Night Vision |
6 warm lights, full color night vision |
Pan&tilt angle |
pan 310 °, tilt 90 ° |
Viewing angle |
Diagonal:91° horizontal:77.3° vertical:42.9° |
Video |
Resolution |
2688*1520P/25FPS/4 MP |
Night Vision |
Full color night vision |
Compression standard |
H.265 /H.264 /MJPEF/JPEG |
IR control |
No IRCUT, full color night vision, automatically adjusting the brightness of the lights according to the environment |
Bit rate |
128~4096kbps |
Image adjustment |
Brightness, contrast, OSD display |
Audio |
Input |
Built-in-38dB microphone |
Output |
Built-in 8Ω2W speaker |
Sampling frequency/bit width |
8KHz/16bit |
Compression standard/Bit Rate |
G711A |
AI |
Humanoid detection |
Humanoid detection, filtering invalid video events |
Object tracking |
Human tracking, automatically following after detecting a person |
Area detection |
Free daub, only monitoring the areas concerned by users |
Smart notification sound |
Different devices push different sounds, so that you can know exactly which device is triggered |
Intelligent alarm sound |
Set different equipment alarm sounds according to different scenarios |
Network |
Network interface |
10Mbps/100Mbps adaptive/RJ45 interface |
Network protocol |
TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P etc. |
Wireless network |
IEEE802.11b/g/n |
Wireless frequency |
2.4/5.2, 5.3,5.6 GHz |
Wireless security encryption |
64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption |
Storage |
External TF card |
Support TF card (up to 256GB) |
Cloud storage |
Support cloud storage |
Alarm |
Alarm detection |
Motion detection, human detection, human framing, human tracking, siren sound, and area detection |
Physical Indicators |
Rated voltage |
DC12V±5% |
Power consumption |
Power: 7.4W (warm light on), maximum power: 12.8W |
Operating condition |
Temperature: -10~50℃; Humidity: <90% |
Weight |
Net weight: 665g; Gross weight: 965g |
Size |
Camera size:169x129x203mm;Packaging box size:270x213x167mm |
Packing list |
Camera, screw pack, warning sticker, screwdriver, manual |
