CS663DR

Detail Specs Videos
  • Support
  • VStarcam CS663DR
    ✮Dual lens dual view leaves no blind spots
    ✮F2.0 large aperture, more light intake, clearer night vision
    ✮ISP image processing technology, preserving true colors
    ✮Human detection, real time alerts
    Sorts Type Parameters
    System Operating system Linux
    Online visitor Supports 4 visitors at the same time
    APP O-KAM Pro
    Collection CPU Ingenic
    Memory 512Mb
    Lens 4mm
    Image sensor 1/2.7" 1080p progressive scan CMOS sensor
    Min. Illumination 0.5Lux (color mode), 0.1Lux (b&w mode)
    Sensor performance Support automatic white balance, automatic gain control and automatic backlight compensation
    Night vision Black and white night vision, full-color night vision
    Viewing angle 91°
    Video Resolution 1080P 1920x1080/15FPS/2MP;1296P 2304x1296/15FPS/3MP
    Night vision Black and white night vision, full-color night vision
    Compression standard H.264 main profile/Motion-JPEG/JPEG
    IR control IR-CUT, soft photosensitive control
    Bit rate 128~4096kbps
    Image adjustment Brightness, contrast, OSD display
    Audio Input Built-in-38dB microphone
    Output Built-in 8Ω1W speaker
    Sampling frequency/bit width 8KHz/16bit
    Compression standard/Bit Rate G711A
    Pan/Tilt Rotation angle Horizontal: 350° Vertical: 90°
    Network Network interface 10Mbps/100Mbps adaptive/RJ45 interface
    Network protocol TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P
    Wireless network IEEE802.11b/g/n
    Wireless frequency 2.4G
    Wireless security encryption 64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption
    Storage External TF card Supports T-Flash cards (up to 256GB)
    Cloud storage Support cloud storage, users can purchase according to their needs.
    Alarm Alarm detection Motion detection, human detection, human framing, siren alarm and area detection
    Physical Indicators Rated voltage DC12V±5%
    Power consumption Power: 6.24W (0.52A) Maximum power: 10.92W (0.91A)
    Operating condition Working temperature: -10~55 ℃, working humidity<90%
    Weight Net weight: 545g . Gross weight: 845g
    Camera size 183x141x237mm
    Packaging box size 253x200x153mm
    Carton size 637x520x425mm,16PCS/CARTON

    Dual lens WiFi camera CS663DR
