| ✮F2.0 large aperture significantly boosts light intake, delivering clearer night vision. | ||
| ✮WIFI PRO connection ensures more stable and reliable signal transmission. | ||
| ✮Full-duplex two-way intercom for smooth real-time communication. | ||
| ✮Dual-chip light panel supports full-color night vision. | ||
| ✮ISP image processing technology restores and preserves true-to-life colors. | ||
| ✮AI-powered human motion detection with instant smart alerts. | ||
| Sorts | Type | Parameters |
| System | Operating system | Linux |
| Online visitor | Supports 4 visitors at the same time | |
| APP | VStarcam Ultra | |
| Collection | CPU | Ingenic |
| Memory | 512Mb | |
| Lens | 4mm | |
| Image sensor | 1/4.5-inch high-quality 1-megapixel CMOS image sensor | |
| Min. Illumination | 0.5Lux (color mode), 0.1Lux (b&w mode) | |
| Sensor performance | Support automatic white balance, automatic gain control and automatic backlight compensation | |
| Night vision | Black and white night vision, full-color night vision | |
| Viewing angle | 58° | |
| Video | Resolution | 720P: 1280×720 / 15FPS / 1.0MP 1080P: 1920×1080 / 15FPS / 2.0MP (interpolated) |
| Night vision | 20-30m | |
| Compression standard | H.264 main profile/Motion-JPEG/JPEG | |
| IR control | IR-CUT, soft photosensitive control | |
| Bit rate | 128～4096kbps | |
| Image adjustment | Brightness, contrast, OSD display | |
| Audio | Input | Built-in -38dB microphone |
| Output | Built-in 8Ω1W speaker | |
| Sampling frequency/bit width | 8KHz/16bit | |
| Compression standard/Bit Rate | G711A | |
| Pan/Tilt | Rotation angle | Pan：270° Tilt：90° |
| Network protocol | TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P | |
| Wireless network | IEEE802.11b/g/n | |
| Wireless frequency | 2.4G | |
| Wireless security encryption | 64/128-bit WEP/WPA-PSK/WPA2-PSK | |
| Storage | TF card | Supports TF card (up to 256GB) |
| Cloud storage | Support cloud storage, users can purchase according to their needs. | |
| Alarm | Alarm detection | Motion detection, human detection, human framing, siren alarm, and area detection |
| Physical Indicators | Rated voltage | DC5V±5% |
| Power consumption | Power: 1.55W (0.31A), Maximum power: 2.8W (0.56A) | |
| Operating condition | Working temperature: -10~55 ℃, working humidity<90% | |
| Weight | Net weight: 386g Gross weight: 686g | |
| Camera size | 146x116x170mm | |
| Packaging box size | 205x160x140mm | |
| Carton size | 580x425x345mm，16PCS/CARTON | |
