| ✮2K Super HD | ||
| ✮Full-duplex two-way audio | ||
| ✮F2.0 large aperture with increased light intake, delivering clearer night vision | ||
| ✮Dual-chip light board, supports 24-hour full-color mode | ||
| ✮ISP image processing technology to restore true-to-life colors | ||
| ✮Intelligent human detection with instant alert push | ||
| Sorts | Type | Parameters |
| Collection | SoC | HI608 |
| Memory | 512Mb | |
| Lens | 4mm | |
| Image sensor | 1/3.3” GC20C3-1080p Progressive Scan CMOS Sensor | |
| Min. Illumination | 0.5Lux (Color), 0.1Lux (B/W) | |
| Sensor performance | Support automatic white balance, automatic gain control and automatic backlight compensation | |
| Night vision | Color Night Vision, Infrared Night Vision | |
| Field of View | 79° | |
| Video | Resolution | 1080P 1920x1080/15FPS/2MP；1296P 2304x1296/15FPS/3MP (Interpolated) |
| Night vision | 10m | |
| Compression standard | H.265 main profile/Motion-JPEG/JPEG | |
| IR control | IR-CUT, soft photosensitive control | |
| Bit rate | 128～4096kbps | |
| Image adjustment | Brightness, contrast, OSD display | |
| Audio | Input | Built-in -38dB microphone |
| Output | Built-in 8Ω1W speaker | |
| Sampling frequency / Bit depth | 8KHz/16bit | |
| Compression standard/Bit rate | G711A | |
| PTZ | Movement range | / |
| Network | Network interface | / |
| Network protocol | TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P | |
| Wireless network | IEEE802.11b/g/n | |
| Wireless frequency | 2.4G | |
| Wireless security | 64/128-bit WEP/WPA-PSK/WPA2-PSK | |
| Storage | External TF card | Support TF card (up to 256GB) |
| Cloud storage | Cloud storage supported (subscription required) | |
| Alarm | Alarm detection | Supports motion detection, human detection, human framing, area detection, and siren alarm. |
| Physical Indicators | Rated voltage | DC5V±5% |
| Power consumption | Power: 1.6W (0.32A)；Max Power: 1.75W（0.35A） | |
| Operating condition | Temperature: -10～55℃; Humidity: ＜90% | |
| Weight | Net Weight: 220g, Gross Weight: 630g | |
| Product Dimension | 190x87x76mm | |
| Package Dimension | ||
| Carton Dimension | ||
| QTY/CTN | ||
| Package Contents | ||
