| ✮3 MP Ultra HD | ||
| ✮F1.6 large aperture for clearer night vision | ||
| ✮Soft light design, presenting full-color images in 24 hours | ||
| ✮ISP image processing technology, preserving true colors | ||
| ✮Human detection, real time alerts | ||
| ✮Remote viewing, anytime, anywhere | ||
| Sorts | Type | Parameters |
| Collection | Operating system | Linux |
| Online visitor | Supports 4 visitors at the same time | |
| APP | O-KAM Pro | |
| Collection | CPU | Sigmastar SSC335 |
| Lens | 4mm F1.6 | |
| Image sensor | 1/2.9 CMOS sensor | |
| Minimum illumination | 0.01Lux | |
| Sensor performance | Support automatic white balance, automatic gain control and automatic backlight compensation | |
| Night Vision | Dual filter automatic switching, 8 leds+8 infrared lights, illumination distance 15-20 meters | |
| View angle | Diagonal: 95 ° Horizontal: 78 ° Vertical: 45 ° | |
| PTZ | Rotation angle | Horizontal 270 °/Vertical 90 ° |
| Preset position | Supports 16 presets (mobile app only supports 5) | |
| Video | Resolution | 2304*1296P/25FPS/3 MP |
| Night Vision | Full color night vision, infrared night vision | |
| Compression standard | H.264+ /H.264 /MJPEF/JPEG | |
| Bit rate | 128～4096kbps | |
| Image adjustment | Brightness, contrast, OSD display | |
| Audio | Input | Built-in-38dB microphone |
| Output | Built-in 8Ω2W speaker | |
| Sampling frequency/bit width | 8KHz/16bit | |
| Compression standard/Bit Rate | G711A | |
| AI | Humanoid detection | Humanoid detection, filtering invalid video events |
| Human tracking | When the camera detects a person, it will automatically follow their trajectory. | |
| Area detection | Free daub, only monitoring the areas concerned by users | |
| Smart notification sound | Different devices push different sounds, so that you can know exactly which device is triggered | |
| Intelligent alarm sound | Set different equipment alarm sounds according to different scenarios | |
| Network | Network interface | 10Mbps/100Mbps adaptive/RJ45 interface |
| Network protocol | TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P | |
| Wireless network | IEEE802.11b/g/n | |
| Wireless frequency | 2.4GHz/5Ghz | |
| Wireless security encryption | 64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption | |
| Storage | External TF card | Supports T-Flash cards (up to 256GB) |
| Cloud storage | Support cloud storage, users can purchase according to their needs. | |
| Alarm | Alarm detection | Motion detection, human detection, human framing, human tracking, siren sound, and area detection |
| Physical Indicators | Rated voltage | DC12V±5% |
| Power consumption | Power: 3.5W (with infrared light on) Maximum power: 11W | |
| Operating condition | Working temperature: -10~55 ℃, working humidity<90% | |
| Weight | N.W：385g G.W.490g (Note: in kind prevail） | |
| Camera size | 133.3*118.3*129.5mm | |
| Packaging box size | 218x146x149mm | |
| What's included | Camera, screw pack, warning sticker, screwdriver, user manual | |
