| ✮4 MP Ultra HD | ||
| ✮5x optical zoom, long-distance high-definition monitoring | ||
| ✮Soft light design，24h color imaging | ||
| ✮ISP image processing technology, preserving true colors | ||
| ✮Human detection, real time alerts | ||
| ✮2.4G/5G WiFi.The wireless signal is strong and stable, and the video won't sutter. | ||
| Sorts | Type | Parameters |
| System | Operating system | Linux |
| Online visitor | Supports 4 visitors at the same time | |
| APP | O-KAM Pro | |
| Collection | CPU | Sigmastar 337DE |
| Memory | 1Gbit | |
| Lens | 5x zoom lens/diagonal 99.3 ° @1X~40.5 °@5X | |
| Image sensor | 1/2.9 CMOS sensor | |
| Minimum illumination | 0.01Lux | |
| Sensor performance | Support automatic white balance, automatic gain control and automatic backlight compensation | |
| Night Vision | Dual filter automatic switching, 6pcs 850nm infrared lights, 6 high-power white lights, 4 red and blue alarm lights, illumination distance 15-20 meters | |
| PTZ | Pan/Tilt | Pan 310°/Tilt 90° |
| Pre-positions | Supports 16 preset positions on PC, 5 on mobile | |
| Video | Resolution | 2688*1520P/25FPS/400w |
| Night Vision | Full color night vision, infrared night vision | |
| Compression standard | H.264+ /H.264 /MJPEF/JPEG | |
| Bit rate | 128～4096kbps | |
| Image adjustment | Brightness, contrast, OSD display | |
| Audio | Input | Built-in -38dB microphone |
| Output | Built-in 8Ω2W speaker | |
| Sampling frequency/bit width | 8KHz/16bit | |
| Compression standard/Bit Rate | G711A | |
| AI | Humanoid detection | Humanoid detection, filtering invalid video events |
| Human tracking | Automatically zooms in and follows the person after it is detected | |
| Area detection | Customize the zone that is concerned by users | |
| Smart notification sound | Different devices push different sounds, so that you can know exactly which device is triggered | |
| Intelligent alarm sound | Set different equipment alarm sounds according to different scenarios | |
| Network | Network interface | 10Mbps/100Mbps adaptive/RJ45 interface |
| Network protocol | TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P etc. | |
| Wireless network | IEEE802.11b/g/n | |
| Wireless frequency | 2.4/5.2, 5.3,5.6 GHz | |
| Wireless security encryption | 64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption | |
| Storage | External TF card | Support TF card (up to 256GB) |
| Cloud storage | Support cloud storage, can purchase according to your need | |
| Alarm | Alarm detection | Motion detection, human detection, human framing, human tracking, siren sound, and area detection |
| Physical Indicators | Rated voltage | DC12V±5% |
| Power consumption | Power: 7.4W (with infrared light on), Max power: 12.8W | |
| Operating condition | Temperature: -10～50℃; Humidity: ＜90% | |
| Weight | Net weight: 705g; Gross weight: 1005g; 12pcs/box | |
| Packing size | Product size: 169x129x203mm; Packing size: 270x213x167mm; Outer box size: 555x520x450mm; | |
| Packing list | Camera, screw pack, warning sticker, screwdriver, user manual | |
