  • Vstarcam CB11
    Model CB11 CB11-TZ (With Solar Panel)
    Category Type Parameters
    System Operating system Linux
    Online visitors Support 4 visitors online at the same time
    Collection Processor T31ZL 1.5GHZ
    Image sensor GC2063, 2MP, 1/2.9 CMOS (pixel optional, PCB compatible)
    Minimum illumination 0.8Lux/F1. 4 (Color mode), 0.3Lux/F1.4 (B&W mode)
    Lens Standard lens 4mm ,1G3P , IR-CUT integrated
    Sensor performance Support Automatic white balance, Automatic gain control, Automatic backlight compensation
    Viewing angle D110 ° diagonal
    Video Night vision Dual light sources, Full color day & night; 2 pcs IR LED lights+2 pcs LED lights
    Compression standard H.264 /MJPEF/JPEG
    Multi code stream 1080p / 15fps, 360p, JPEG capture
    IR control IR turned on-- the Night vision ON; IR, ICR automatic detection; IR turned off-- the Night vision function disabled/ IR always OFF, ICR is fixed in the Day vision mode
    Bit rate CBR / VBR two rate control modes, and the output rate range is 128 ~ 4096kbps
    Image adjustment Brightness, contrast, vertical, horizontal adjustable, OSD display
    Audio Input Built-in - 38dB microphone
    Output Built-in 8 Ω 2W speaker
    Sampling frequency / Bit width 8KHz/ 16bit
    Compression standard / Bit rate G711A
    Network Network protocol TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,P2P,IPV4 etc
    Wireless network IEEE802. 11b/g/n
    Wireless frequency 2.4~2.4835GHz
    Wireless security encryption 64/ 128-bit WEP/WPA -PSK/WPA2 -PSK data encryption
    Wireless connection AP hotspot network configuration, QR code network configuration
    Key Key 1 Power ON/OFF
    Reset Key Long Press to restore the factory settings
    Storage Storage function Support T-Flash card (up to 256GB)
    Alarm Alarm detection Support PIR human detection; Detection distance: 8m
    Physical indicators Rated voltage DC5V±5%
    Power supply Comes with 12000mAh battery power supply, supports external 5V solar panels
    Power consumption Sleep current 500uA, Working current: 390mA
    Work environment Working temperature: - 10 ~ 55 ℃, Working humidity < 90%
    Weight Gross weight: TBD (Note: in kind prevail)
    Size TBD
    Packing list Camera * 1, Bracket * 1, MICRO USB* 1, Manual * 1,(Solar panel*1, Solar panel bracket*1 optional)

    Intelligent WiFi battery camera
