Detail Specs Videos
  • Support
    1. Exclusive private model, 3MP, 2.5 inch
    2. PIR detection alarm, Within 1 second recording;
    3. Support 20000 mAhbattery power supply and Low-battery alert;
    4. IP66 waterproof, rainproof & dustproof, Two-way talk;
    5. Cloud Storage, TF card storage, Max supports 256G
    6. Humanoid detection and alarm pushing;
    7. Free Cloud Storage recording
      SystemOperating systemEmbedded Linux
      Online visitorSupports 4 visitors at the same time
      CPU/Image sensor1/2.9 inch 1080p progressive scan CMOS sensor
      Minimum illumination0.5 Lux(Color mode), 0.1 Lux(B&W mode)
      Lens/Viewing angle3.6mm@F2.0/101° Diagonal
      Night visionIR-CUT with auto-switching,6PCS IR LED lights; Irradiation distance: 10~15 m
      Compression standardH.264 main profile/H.264+ main profile/Motion-JPEG/JPEG
      Data RateMain stream: 1080p(1920×1080)@15fps
      Bit rate/maximum frame rate128~4096kbps/15fps
      Image adjustmentBrightness and contrast are adjustable
      AudioInputBuilt-in -38dB microphone
      OutputBuilt-in 8Ω2 W speaker
      Sampling frequency/bit width8KHz/16bit
      Compression standard/Bit RateG.711/64kbps
      NetworkNetwork configurationQR code, AP network configuration
      Network protocolTCP/IP, HTTP, TCP, UDP, DHCP, DNS, NTP, P2P etc.
      Wireless networkIEEE802.11b/g/n;Supports AP mode
      Wireless frequency2.4~2.4835GHz
      Wireless security encryption64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption
      Pan & TiltPan & TiltPan 345° /Tilt 55°
      Preset positionSupports 16 (Mobile phone App supports 5) preset positions
      StorageStorage functionsSupports T-Flash card(max supports 256GB); Cloud Storage
      AlarmAlarm detectionRadar detection; Humanoid detection
      Physical IndicatorsRated voltageDC5V±5%
      Power supplySupports four 18650 or four 21700 batteries
      PowerRated power:5W (with IR LED lights ON)/Max power:11W (with Pan & Tilt ON)
      Operating conditionTemperature: -10~50℃; Humidity: <90%
      WeightNet: 604g(Note: in kind prevail)
      Package size205x205x146mm(Note: in kind prevail)

    Smart Waterproof Wireless Battery Camera CB69
