| ✮Wireless connection | ||
| ✮Remote active wake-up, two-way voice intercom | ||
| ✮Quick start, start recording within 400ms | ||
| ✮Intelligent detection of human movement, intelligent alarm push | ||
| ✮5200mAh battery power supply, low power warning | ||
| ✮Ultra low power system optimization | ||
| ✮Free cloud storage alarm video | ||
| ✮Support external 2W/3W solar panels, continuously transmit power, and the equipment won't not powered off | ||
| Model | CB54 | CB54-TZ (With Solar Panel) |
| Category | Type | Parameter |
| System | Operating system | Embedded Linux |
| Online visitor | Supports 4 visitors at the same time | |
| APP | O-KAM Pro | |
| Collection | Processor | T23ZN |
| Memory | 8M | |
| Image sensor | GC2083 200W,1/2.9 CMOS | |
| Minimum illumination | 0.8Lux/F1.4（(Color mode)）,0.3Lux/F1.4（B&W mode） | |
| Lens | Standard lens 4mm，1G3P，IR-CUT integrated | |
| Sensor performance | Support Automatic white balance, Automatic gain control, Automatic backlight compensation | |
| Viewing angle | D110° Diagonal | |
| Video | Night vision | Black and white night vision, Automatic switching of IR-CUT, 6 pcs 850nm IR LED lights, Night vision irradiation distance: 5 ~ 10m |
| Compression standard | H.264 /MJPEF/JPEG | |
| Multi-stream | 1080P/15fps | |
| IR control | IR night vision enables; IR, ICR automatic detection; IR OFF night vision function disabled/ IR always OFF, ICR is fixed in the day vision mode | |
| Bit rate | CBR / VBR two rate control modes, and the output rate range is 128～4096kbps | |
| Image adjustment | Brightness, contrast, OSD display | |
| Audio | Input | Built-in－38dB microphone |
| Output | Built-in 8Ω1W speaker | |
| Sampling frequency/bit width | 8KHz/16bit | |
| Compression standard / Bit rat | G711A | |
| Network | Network protocol | TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P,IPV4 etc |
| Wireless network | IEEE802.11b/g/n/ax | |
| Wireless frequency | 2.4/5.8GHz | |
| Wireless security encryption | 64/128-bit WEP/WPA-PSK/WPA2-PSK/WPA3 Data encryption | |
| Wireless connection | Bluetooth network configuration, QR code network configuration | |
| Key | Key1 | Power ON/OFF |
| Reset key | Long Press to restore the factory settings | |
| Storage | Storage capacity | Support T-Flash card (max 256GB) |
| Alarm | Alarm detection | Support PIR human detection; Detection distance: 6m |
| Physical Indicators | Rated voltage | DC5V-1A |
| Power supply | Comes with 5200mAh battery power supply，2*18650，supports extern2V, 3V solar panels | |
| Power consumption | Sleep current 500uA，Working current：390mA | |
| Operating condition | Temperature: -10～50℃; Humidity: ＜90% | |
| Weight | Net weight: 192.2g, gross weight: 205.2g, weight of one carton: 13.56kg | |
| Packing list | Camera*1，Bracket*1，charging cable*1, Manual*1（Solar power panel*1 Optional） | |
