High-Speed WiFi Pro
Dual Lens Network
Camera
Dual Lens Dual Views
Two Way Audio
Humanoid Detection
5 MP HD Resolution
With a 5 MP high definition lens,
the camera presents images
with vivid colors and sharp details
High-Speed WiFi Pro Transmission, Strong and Fast
The camera adopts High-Speed WiFi Pro wireless transmission,
with strong and stable signals, ensuring no delay or lag in video and voice calls
Dual Lens Simultaneous Monitoring
Equipped with a wide-angle lens and a tracking lens, the camera can protect two areas
simultaneously with just one installation and wiring, minimizing the installer’s efforts and charges
Color Night Vision, 24H Color Image
It adopts ISP image processing technology. Three clear
night vision modes are available for you to choose
Pan & Tilt to Cover More Areas
The camera can pan and tilt so you can check any important corners.
When it detects a human, it automatically tracks their movement, records the entire process
and pushes real-time notifications to the user’s phone.
Humanoid Detection, Real Alarm
When the camera detects a human figure, it will immediately
push an alarm message to the phone and activate the
alarm light to remind the user to deal with the
abnormal situation in time
Smart Tracking
With smart auto-tracking, this camera can automatically
track moving people wherever they go, letting you know
more details before and after an event.
Sound Light Alarm to
Warn Off Criminals
When the camera detects a motion, its powerful lights
and siren will be activated to deter potential criminals.
Two Way Communication
The camera uses high-quality components and technology for professional noise reduction. With the two-way voice function,
you can clearly communicate remotely with the people on the camera end no matter where you are
TF Card and Cloud Storage
Store the videos locally in a TF card. Or upload the alarm videos to the cloud. Through the App,
you can play back the video anytime and anywhere without missing any critical moments.
Share with Your Family
Share the account with your families to enjoy a simultaneous live view (up to 4 users)
and experience every happy and unforgettable moment together
Various Application Scenarios
Multi-terminal Viewing
It supports real-time viewing on multiple mobile and PC terminals.
Simple and Fast Networking
What’s in the Box?
Qualification Certificate
ISO 27001/ISO 9001/PSE Certification/CQC Product Certification/CE/ROSH/FCC
UN38.3 Certification/Integrity Enterprise Certification
| ✮Dual lens dual view leaves no blind spots | ||
| ✮WiFi connection | ||
| ✮F2.0 large aperture, more light inputs, clearer night vision | ||
| ✮ISP image processing technology, preserving true colors | ||
| ✮Dual channel real-time recording, guarding multiple directions | ||
| ✮Human detection, real time alerts | ||
| Sorts | Type | Parameters |
| System | Operating system | Linux |
| Online visitor | Supports 4 visitors at the same time | |
| APP | O-KAM Pro | |
| Collection | CPU | Ingenic |
| Memory | 512Mb | |
| Lens | 4mm | |
| Image sensor | 1/2.7" 1080p progressive scan CMOS sensor | |
| Minimum illumination | 0.5Lux (color mode), 0.1Lux (b&w mode) | |
| Sensor performance | Support automatic white balance, automatic gain control and automatic backlight compensation | |
| Night vision | Black and white night vision, full-color night vision | |
| Viewing angle | Diagonal : 91 ° | |
| Video | Resolution | 1080P 1920x1080/15FPS/2MP；1296P 2304x1296/15FPS/3MP |
| Night vision | Black and white night vision, full-color night vision | |
| Compression standard | H.264 main profile/Motion-JPEG/JPEG | |
| IR control | IR-CUT, soft photosensitive control | |
| Bit rate | 128～4096kbps | |
| Image adjustment | Brightness, contrast, OSD display | |
| Audio | Input | Built-in -38dB microphone |
| Output | Built-in 8Ω1W speaker | |
| Sampling frequency/bit width | 8KHz/16bit | |
| Compression standard/Bit Rate | G711A | |
| Pan&Tilt | Angle | Pan：340° Tilt：90° |
| Network | Network interface | 10Mbps/100Mbps |
| Network protocol | TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P | |
| Wireless network | IEEE802.11b/g/n | |
| Wireless frequency | 2.4G | |
| Wireless security encryption | 64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption | |
| Storage | External TF card | Supports T-Flash cards (up to 256GB) |
| Cloud storage | Support cloud storage, users can purchase according to their needs. | |
| Alarm | Alarm detection | Motion detection, human detection, human framing, area detection, human tracking |
| Physical Indicators | Rated voltage | DC5V±5% |
| Power consumption | Power: 2.6W (0.52A) Maximum power: 4.15W (0.83A) | |
| Operating condition | Working temperature: -10~45 ℃, working humidity<90% | |
| Weight | Net weight: 319g Gross weight: 620g | |
| Camera size | 116x114x114mm | |
| Packaging box size | 124x120x178mm | |
| Carton size | 640x620x380mm, 50PCS/carton | |
