CS49

Detail Specs Videos
  • Support
  • CS49 3MP HD Smart WIFI IP Camera PTZ home camera

                     Sorts                  Type                                           Parameters
      System                           Operating system Embedded Linux
    Online visitor Supports 4 visitors at the same time
    CPU/Image sensor 1/2.9 inch 1080p progressive scan CMOS sensor
    Minimum illumination 0.5 Lux(Color mode), 0.1 Lux(B&W mode)
    Lens/Viewing angle 3.6mm@F2.0/101°  Diagonal
    Night vision IR-CUT with auto-switching,6 pcs IR LED lights; Irradiation distance: 5~10 m
    Compression standard H.264 main profile/H.264+ main profile/Motion-JPEG/JPEG
    Data rate Main stream: 1296p(2304×1296)@15fps/1080p(1920×1080)@30fps Substream:360p(640×360)@15fps
    Bit rate/maximum frame rate 128~4096kbps/30fps
    Image adjustment Brightness and contrast are adjustable
      Audio Input Built-in -38dB microphone
    Output Built-in 8Ω1W speaker
    Sampling frequency/bit width 8KHz/16bit
    Compression standard/Bit Rate G.711/64kbps
      Network Network interface 10Mbps/100Mbps adaptive /RJ45 interface
    Network protocol TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P、ONVIF etc.
    Wireless network IEEE802.11b/g/n; Supports AP mode
    Wireless frequency 2.4GHz
    Wireless security encryption 64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption
      Pan & Tilt   Pan & Tilt   Pan 350° /Tilt 70°
    Preset position Supports 16 (Mobile phone App supports 5) preset positions
      Storage Storage functions Supports T-Flash card(max supports 256GB); Cloud Storage;NVR;NAS
      Alarm         Alarm detection         Supports Motion detection; Humanoid detection; Humanoid framing; Smoke sound detection; Absence detection; Delimitation detection
      Physical Indicators Rated voltage DC 5V±5%
    Power consumption Rated power: 2.2W (with IR LED lights ON)/ Max power: 5.5W(with Pan & Tilt ON)
    Operating condition Temperature: -10~50℃; Humidity: <90%
    Weight Net: 190g  (Note: in kind prevail)
    Package size 158x146x106mm
