  • NVR
    Video Input IP Video Input 9 CH 720P/960P/1080P,RJ45 interface
    Switch NO
    Video Encoding HDMI Output 1  CH ,HDMI output ;Resolution:1920x1080P/60Hz;
    VGA  Output 1  CH ,VGA   output ;Resolution:1920x1080P/60Hz
    Audio Output  HDMI Audio output, optional for 3.5mm audio port output
    Video Encoding Video Compression stander  H.265, H.264
    Recording /Playback 9CH 1080P record,  2 CH 1080P playback
    Video Resolution 720P,960P,1080P record
    Frame Rate PAL: 25 F/S;NTSC :30  F/S
    Video Bitrate 256 Kbps -- 4.0Mbps(@1080P)
    Stream Type Audio/Video,Variable Rate(VBR) , Constant Bit Rate(CBR)
    Dul-Stream supprt
    Audio Compression G.711
    Stream 70Mbps
    HDD Storage Type 1 *  SATA
    Storage Capacity 6TB In Max
    Backup USB Backup,remote backup
    External Interface Network Interface RJ45 10M / 100M Internet Interface
    USB Interface 2 * USB2.0 Interface(Support Upgrade,Backup,Mouse)
    Serial Interface 1 * RS485 Interface
    Others Temperature -10°---- 55°
    Size TBD
    Weight TBD
    Operation System Embedded Linux Operation System
    Soft Power-Off Not Support
    Device Control  IR remote control,Mouse
    Power Input DC +12 V / 2A
    System Operation system Embedded Linux OS
    Online visitor Support 4 visitors at the same time
    Image Capture Image sensor 1/2.9 inch 1080p Progressive Scan CMOS
    Minimum Illumination 0.3~0.5Lux(color mode),0Lux(B&W mode)
    Lens/View Angle 4mm@F2.0/101˚(Diagonal)
    Nightvision Dual Filter,IR-Cut,18pcs 850nm patch IR LED,
      IR irradiation distance:15m
    Video Encode format H.264+/H.264 main profile/Motion-JPEG/JPEG
    Streams Main stream:1080p(1920×1080)@30fps/1296p(2304×1296)@30fps
    Bit Rate/Max Fps 128~4096kbps/30pfs
    Image adjustment Brightness and contrast can be adjusted
    Audio Input Built-in -38db microphone
    Network Ethernet 10Base-T / 100Base-TX, RJ45 connector
    Wireless LAN IEEE802.11b/g/n, Supports AP mode
    Wireless LAN Frequency 2.4~ 2.4835GHz
    Wireless LAN security 64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption
    Memory Socket TF Push-push socket,(support maximum 256GB); Cloud Storage;NVR;NAS
    Alarm Alarm Trigger Motion detection, Humanoid detection,Absence monitoring
    Rated voltage DC12V±5%
    Power consumption Related power:6W
    Operating condition Temperature:-10~50℃,humidity:<90%
    Weight Net: 230g Gross:450 g (Note: in kind prevail)
    Package size 265x130x85 mm (L×W×H)
