CS664

Detail Specs Videos
  • Support
  • Sorts Type Parameters
    System Operating system Embedded Linux
    Online visitor Supports 4 visitors at the same time
    CPU/Image sensor 1/3 inch 1080p progressive scanning CMOS sensor
    Minimum illumination 0.5 Lux(Color mode),  0.1 Lux(B&W mode)
    Lens/Viewing angle 4mm@F2.3/101°Diagonal
    Night Vision IR-CUT with auto-switching, Double light source 32 lights,Irradiation distance20-30 m
    Compression standard H.264 main profile/Motion-JPEG/JPEG
    Data rate Main stream:1080p(1920×1080)@15fps;Substream:360p(640×360)@15fps
    Bit rate/maximum frame rate 128~4096kbps/30fps
    Image adjustment Brightness, contrast are adjustable
    Audio Input Built-in-38dB microphone
    Output Built in 8 Ω 2W speaker
    Sampling frequency/bit width 8KHz/16bit
    Compression standard/Bit Rate G.711/64kbps
    Network Network interface 10Mbps/100Mbps adaptive /RJ45 interface
    Network protocol TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P etc.
    Wireless network IEEE802.11b/g/n;Support AP mode
    Wireless frequency 2.4~2.4835GHz
    Wireless security encryption 64/128-bit WEP/WPA-PSK/WPA2-PSK Data encryption
    Pan & Tilt    Pan & Tilt   Pan 345°/Tilt 90 °
    Preset position Supports 16 (Mobile phone App supports 5) preset positions
    Storage Storage functions Support T-Flashcard(max256GB); Cloud storage; NVR;NAS
    Alarm Alarm detection Support motion detection, humanoid detection, humanoid tracking, alarm voice prompt, burst flash and illumination functions, and white light regular start and stop functions
    Physical Indicators Rated voltage DC12V±5%
    Power consumption Rated power:W  (with IR LED lights ON)/Max Power: W (with Pan & Tilt ON)
    Operating condition Temperature: -10~50℃; Humidity: <90%
    Weight (Note: in kind prevail)
    Packaging Size mm TBD
