    SystemOperation systemEmbedded Linux OS
    Online visitorSupport 4 visitors at the same time
    Image CaptureImage sensor1/2.9 inch 1080p Progressive Scan CMOS
    Minimum Illumination0.3~0.5Lux(Color mode),0Lux(B&W Mode)
    View Angle101°(Diagonal)
    Night visionAutomatic switching of dual filters, six 850nm infrared lamps and four high-power white lamps, with irradiation distance of 15-20 meters
    VideoEncode formatH.264+/H.264 main profile/Motion-JPEG/JPEG
    StreamsMain stream:1080p(1920*1080)@30fps/1296p(2304*1296)@15fps Sub stream:360p(640*360)@15fps
    Bit Rate/Max Fps128~4096kbps/30pfs
    Image adjustmentBrightness and contrast can be adjusted
    AudioInputBuilt in -28db microphone
    OutputBuilt-in 8Ω2w speakers
    Sampling frequency / width8KHz/16bit
    Compression standardADPCM/32kbps
    NetworkEthernet10Mbps/100Mbps adaptive /RJ45 interface
    Wireless LANIEEE802.11b/g/n, Supports AP mode
    Wireless LAN Frequency2.4~ 2.4835GHz
    Wireless LAN security64/128-bit WEP/WPA-PSK /WPA2-PSK data encryption
    Preset positionPC APP:support 16 positions,  Phone APP:support 5 positions
    MemorySocketTF Push-push socket,Maximum support 256GB; Cloud Storage;NVR;NAS
    AlarmAlarm TriggerSupport motion detection, human detection,  absence monitoring
    Physical EnvironmentalRated voltageDC12V±5%
    Power consumptionRelated power:8.5W(IR on)
    Operating conditionTemperature:-10~50℃,humidity:<90%
    WeightNet: 875g  Gross:TBD g(Note: in kind prevail)
    Package size205x195x130mm(L*W*H)
