CS69

Detail Specs Videos
  • Support
    1. Exclusive private model, 3MP, 2.5 inch;dual light sources
    2. Red & blue lights alarm;
    3. Dual light sources; Night vision: 15-20 m;IR LED light + LED light.
    4. Two-way talk; Rainproof & dustproof; IP66 waterproof;
    5. Cloud Storage, TF card storage, Max supports 256G;
    6. Humanoid framing, Humanoid tracking, Humanoid detection, Delimitation detection
    7. LEDlight Timing ON& OFF
      SortsTypeParameters
      System        Operating systemEmbedded Linux
      Online visitorSupports 4 visitors at the same time
      CPU/Image sensor1/2.9 inch 1080p progressive scan CMOS sensor
      Minimum illumination0.5 Lux(Color mode), 0.1 Lux(B&W mode)
      Lens/Viewing angle4mm@F2.0/101° Diagonal
      Night visionIR-CUT with auto-switching,IR LED light + LED light, Irradiation distance: 15-20 m.
      Compression standardH.264 main profile/H.264+ main profile/Motion-JPEG/JPEG
        Data RateMain stream: 1080p(1920×1080)@30fps/1296p(2304×1296)@15fps Substream:360p(640×360)@15fps
      Bit rate/maximum frame rate128~4096kbps/30fps
      Image adjustmentBrightness and contrast are adjustable
      AudioInputBuilt-in -38dB microphone
      OutputBuilt-in 8Ω2 W speaker
      Sampling frequency/bit width8KHz/16bit
      Compression standard/Bit RateG.711/64kbps
      NetworkNetwork interface10Mbps/100Mbps adaptive /RJ45
      Network protocolTCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P etc.
      Wireless networkIEEE802.11b/g/n;Supports AP mode
      Wireless frequency2.4~2.4835GHz
      Wireless security encryption64/128-bit WEP/WPA-PSK/WPA2-PSK  data encryption
      Pan & Tilt  Pan & Tilt  Pan 345° /Tilt 53°
      Preset positionSupports 16 (Mobile phone App supports 5) preset positions
      StorageStorage functionsSupports T-Flash card(max supports 256GB); Cloud Storage; NVR;NAS
      AlarmAlarm detectionSupports Motion detection; Humanoid detection; Humanoid tracking; Smoke sound detection; Absence detection; LED light Timing ON & OFF
      Physical IndicatorsRated voltageDC12V±5%
      Power consumptionRated power:5W (with IR LED lights ON)/Max power:11W (with Pan & Tilt ON)
      Operating conditionTemperature: -10~50℃; Humidity: <90%
      WeightNet: 472 g(Note: in kind prevail)
      Package sizeTBD

    CS69 PT Outdoor Security Camera
